Hebei Forever Electromechanical Factory is a professional research and development manufacturer of seamless pipe induction annealing machine and various induction heat treatment equipment in China. Over the years, Forever Electromechanical Factory has become a benchmark enterprise in the industry with excellent quality and high-quality service. Forever Steel Pipe Annealing Furnace Manufacturer can customize complete technical solutions for customers according to their actual needs!
The medium frequency annealing equipment for steel pipes is designed with manual and automatic power adjustment knobs, with automatic being the temperature closed-loop control mode.
Advantages of steel pipe induction annealing furnace :
1. The sensor copper tube of the seamless steel pipe annealing furnace is wrapped with T2 oxygen free copper, with a wall thickness of 3.0mm or more. The insulation material of the sensor has high strength, high temperature resistance, and a longer service life;
2. The inlet and outlet ends of the sensor are sealed with 5mm copper plates, which infinitely reduces magnetic leakage and extends its service life.
3. The sensor chassis is made of high-strength aluminum alloy to reduce the impact of magnetic leakage and heating on other components. A water-cooled roller is installed between every two sensors, and each roller is equipped with a variable frequency speed control motor.
4. The roller conveyor between the furnace bodies is made of 304 non-magnetic stainless steel and water-cooled. The feeding system of the seamless steel pipe continuous annealing equipment is driven by an independent motor reducer for each shaft, controlled by an independent frequency converter, and flexibly designed with speed difference output. The operating speed is controlled in segments.
5. The control of seamless steel pipe annealing furnace is proficient, with a strict level management system and a comprehensive one click reduction system.
6. Language switching can be provided according to different countries and regions.
Overseas manager: Tom Wang
Email:tom@foreverfurnace.com
Phone: 0086-13303078975(whatsapp, wechat,line)
Specialist of bar heat treatment furnace in China; Glad to be your business partner in induction heating field.
Post time: 12-06-2024
